(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Bridge Rectifier<^< Worksheet: Full-wave Rectifier | Course Index | Worksheet: Bridge Rectifier >^>(:nl:)  An alternative form of full-wave rectifier is the bridge rectifier. This circuit uses four similar diodes in which opposite pairs conduct on alternate half-cycles. This arrangement avoids the need to have two separate secondary windings (as in the bi-phase rectifier circuit). On positive half-cycles, point A will be positive with respect to point B. In this condition D'_1_' and D'_2_' will allow conduction whilst D'_3_' and D'_4_' will not allow conduction. Conversely, on negative half-cycles, point B will be positive with respect to point A. In this condition D'_3_' and D'_4_' will allow conduction whilst D'_1_' and D'_2_' will not allow conduction. As with the bi-phase rectifier, the switching action of the two diodes results in a pulsating output voltage being developed across the load resistor, R'_L_'. (:nl:)(:table style="clear:both":)
| |
