(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Electrostatics<^< Electronic Principles | Course Index | Electric Fields >^>(:nl:) (:video_flv-player Attach:elecstat_9.flv width=380 height=252 params= startimage= We can demonstrate the force that exists between electric charges by suspending a positively charged glass rod. If a second - positively charged - glass rod is held close to the suspended glass rod, the suspended rod will twist away from the other rod, as shown. This shows that "like charges repel". If a second - negatively charged - ebonite rod is held close to the suspended glass rod, the suspended rod will twist towards the other rod, as shown. This shows that "unlike charges attract". (:nl:)(:table style="clear:both":)
| |
