(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Input Resistance<^< Worksheet: Voltage Gain | Course Index | Output Resistance >^>(:nl:)  The input resistance of an operational amplifier is defined as the ratio of input voltage to input current expressed in ohms. It is often expedient to assume that the input of an operational amplifier is purely resistive though this is not the case at high frequencies where shunt capacitive reactance may become significant. The input resistance of operational amplifiers is very much dependent on the semiconductor technology employed. In practice values range from about 2 MΩ for common bipolar types to over 10'^12^'Ω for FET and CMOS devices. Input resistance is the ratio of input voltage to input current: R'_IN_' = V'_IN_'/I'_IN_' where R'_IN_' is the input resistance (in Ω), V'_IN_' is the input voltage (in V) and I'_IN_' is the input current (in A). (:nl:)(:table style="clear:both":)
| |
