(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Measuring Resistance<^< Examples: BS1852 Resistor Coding | Course Index | Resistor Symbols >^>(:nl:) (:video_flv-player Attach:measures_3.flv width=352 height=288 params= startimage= The video shows how an analogue multimeter is used to measure the resistance of a resistor. Before carrying out the measurement it is important to ensure that the meter is correctly zeroed on the ohms range. This involves shorting the test leads together and adjusting the set zero control to obtain full-scale deflection on the meter (the pointer moves to the extreme right-hand of the scale). Once the meter has been zeroed, the test leads are placed on the resistor leads and the scale reading is noted. In this case, the meter resistor has a resistance of 39 ohms. This value agrees with that indicated by the resistor's colour code. (:nl:)(:table style="clear:both":)
| |
