(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Left or Right<^< Set up the Equipment | Course Index | Create New Macros >^>(:nl:) We are going to modify the flow chart that you developed for the car indicators. Remember this?  A large part of the flow chart is taken up with causing either the left or the right indicator to flash. The only difference between these two operations is the number that is sent to the output port. We are going to create a macro that outputs whatever number we give it, pauses, then outputs zero, and pauses again. (:nl:)(:table style="clear:both":)
| |
