(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login A More Useful Counter<^< Other LCD Functions | Course Index | Binary Numbers >^>(:nl:) # Expand your program by dragging a Loop icon below the 'PrintString' Component Macro. # Change the text in the 'PrintString' Component Macro to "Hundredths:" (with quotation marks). # Drag a Calculation icon into the Loop. Set up a variable called "Count" as an 'Int' type. Double-click on the Calculation icon. In the 'Calculations:' text box type "Count = Count + 1". This will add 1 to the value of variable count every time the icon is executed. # Next drag another Component Macro into the Loop. Double-click the Component Macro and find 'Cursor' under the 'LCD' macros and enter '0,1' in the parameters. This will position the cursor on the first character of the second line. # Next drag another Component Macro onto the workspace and do the same but select 'PrintNumber' instead and enter "Count" as the parameters. # Next drag a Delay icon into the program and set the delay to 10ms or a hundredth of a second. # Go over the program and click on each icon entering comments on what each icon does. This seems like a lot of effort, but if you can discipline yourself to entering comments you will save time in the long run as your programs will be easier to read. # Run the program. You have now made a counter that will count (approximately) the time elapsed in hundredths of seconds.  (:nl:)(:table style="clear:both":)
| |
