(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Other LCD Functions<^< Writing Messages | Course Index | A More Useful Counter >^>(:nl:) There are a number of other useful functions in the LCD macro list: ClearClears the display and resets the cursor (the position the display will print on next) to 0,0 - top left. CursorMoves the cursor to the specified location. This takes two parameters X and Y, corresponding to the horizontal and vertical position respectively. 0,0 is the top left position on the display. 0,1 is the first letter of the second line. 3,2 would represent the fourth letter of the third line. PrintNumberThis works like 'PrintString' but prints the number instead of the string. Can be used with variables, or actual numbers. PrintNumber example:If you add a Component Macro icon, select 'Cursor' and add 0,1 to the parameters. Create another Component Macro icon and select 'PrintNumber' with the parameter value as '123'. Finally create another and select 'PrintString' and add "Hello World" (with quotation marks) to the parameter. Now click 'Run' to simulate the program, you should see results similar to this:  PrintASCII and CommandThese are more advanced features that you will learn about later. For now you can ignore them.(:nl:)(:table style="clear:both":)
| |
