(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login LED Board EB004<^< Sensor Interface (EB003) | Course Index | LCD Board (EB005) >^>(:nl:) EB004 LED BoardMore information can be found here.  EB004 LED Board Block Diagram * Click EB004-30-2 for the datasheet. * The male D-type connector fits into the Female connector of one of the ports of an upstream board. * LED D0 and its series resistor R0 will be connected to pin 1 of the Male D-type connector * The series resistor is here to control the current that will flow from PICmicro to the LED. ** A LED usually has an Imax of 20mA ** The PICmicro has an Imax of 25mA (sink or source) ** The LED has a Forward Voltage drop of 1.7V ** In this case the 560 Ohm resistor will limit the current at: *** (5V-1.7V)/560 Ohm= 5.9mA *** This is well under the current limits of both PICmicro and LED * The Female connector is here to connect several boards in parallel. Be ware of the total current limit of the PICmicro if you do so. (:nl:)(:table style="clear:both":)
| |
