(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Adding the Switches<^< Adding the LED array | Course Index | Simulation >^>(:nl:) You will use a single push switch. # Click once on the Inputs and select 'Push Round Panel' # Ensure the 'Connection' property under the 'Connections' section on the Properties Panel is connected to '$PORTA.0' # Click and drag the 'Text' button from the System Panel toolbar and place it next to the switch. Click on the 'Text' property in the Properties pane and replace the text with "Light beam interruption" in the text box. Manipulate the element using the 'Scale' section on the Properties Panel and move it to a suitable position next to the button. You should now have a project that looks something like this:  (:nl:)(:table style="clear:both":)
| |
(:Summary: Website page footer:)
Print - (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) Search - Login
Page last modified on July 22, 2013, at 10:07 AM
icon. Add or drag it onto the System Panel.
