(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Set up the Calculation<^< Create the Variables | Course Index | Loop Properties >^>(:nl:) # Double-click on the Calculation icon to open the Properties dialogue box.  # Change the Display name to "New total". # Tell the Calculation icon what it is supposed to calculate by typing the following equation in the Calculations window: ->TOTAL = TOTAL + SHEEP ->We are going to simulate the light beam using a single push switch on Port A bit 0 - the switch marked 'SW0' on the switch board. ** The Input Properties are set up to store whatever number appears on port A in the variable called 'SHEEP'. ** When the switch is not pressed, the number on Port A is 0, and this is stored in the variable 'SHEEP'. ** When we press the switch, the number 1 is inputted via Port A, and stored in the variable 'SHEEP'. ->(As we are using only one switch, the biggest number we can produce on Port A is 1.) ->When the Calculation icon is activated, the number stored in the variable 'SHEEP' is added to the 'TOTAL' variable. When a sheep breaks the light beam, in other words, then 'TOTAL' is increased by 1. When no sheep is present, 'TOTAL' remains unchanged. # Then click on the OK button, to close the dialogue box. (:nl:)(:table style="clear:both":)
| |
