(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login PORT C<^< PORT B | Course Index | PORT D >^>(:nl:) * Full 8 pins of Port C can be used on a 16F1937 device * RC0-RC7 can be used as digital inputs * RC0-RC7 can be used as digital outputs * PWM (Pulse Width Modulation) is possible on RC1 and RC2 * Port C also contains a USART (Universal Synchronous - Asynchronous Receiver Transmitter) and a MSSP (Master Synchronous Serial Port) for serial communication  * The pins of Port C are mapped on the 16F1937 microcontroller as on this drawing  * The pins of Port C are connected to the 9-pin D-type connector of Port C on the Multiprogrammer board. This port is connected to the rest of the PICmicro internals by an 8-bit bus system.  (:nl:)(:table style="clear:both":)
| |
