(:Summary:Contains the 'action' links (like Browse, Edit, History, etc.), placed at the top of the page, see site page actions:) (:comment This page can be somewhat complex to figure out the first time you see it. Its contents are documented at PmWiki.SitePageActions if you need help. :) * Print (:comment (:if group Site,SiteAdmin,Cookbook,Profiles,PmWiki*:) (:comment delete if and ifend to enable backlinks:) * %item rel=nofollow class=backlinks accesskey='$[ak_backlinks]'% [[{*$Name}?action=search&q=link={*$FullName} | $[Backlinks] ]] (:ifend:) :) * Login Timer 0<^< Timer 1 | Course Index | RB0 Interrupt >^>(:nl:) Largely simplified block schematic to demonstrate where the 'Timer 0' ('TMR0') is located in the PIC 16F1937 Architecture:  TMR0:* This timer interrupt is used to provide the PICmicro with exact timing info. * It is clocked by the system clock or by an external clock on RA4. * This system clock runs exactly 4 times slower than the external oscillator clock. * Either the external clock or the system clock can be divided by 1, 2, 4 or 8, 16, 32, 64, 128, or by 256 by configuring the Prescaler of TMR0 in Flowcode. * This divided clock triggers TMR0 to increment the TMR0 register. * This TMR0 register is an 8-bit register and will have an overflow when it reaches 256. * On the exact moment when this overflow occurs, TMR0 generates an interrupt and the TMR0 register is set back to 0. * This TMR0 Interrupt will stop the main program immediately and start up the TMR0 Macro. * After the TMR0 Macro is finished, the main program goes further where it had left before. Example:
Conclusion: In this situation, TMR0 will interrupt the main program and execute the TMR0 macro 75 times per second. (:nl:)(:table style="clear:both":)
| |
